Vertical Ribbon Mixer by Polyc Machine
Product Features:
Ribbon Blender Mixer is a newest mixing equipment with high efficiency, high uniformity, high loading coefficient but low energy cost, low pollution and low crush. The special design of double ribbon mixer the materials into high uniformity in a few minutes. On the other hand, ribbon blender mixer shows a wide application from powder mixing, powder-liquid, to paste or materials in high specific gravity (such as putty, really stone paint, metal powder and other materials) and becomes one of the most popular single shaft horizontal mixing equipment.
Working Principle:
Ribbon blender mixer consists of drive disk assembly, double layer ribbon agitator, U-shape cylinder. Inside ribbons move materials toward the ends of the ribbon blender whereas the outside ribbons move material back toward the center of the ribbon blender, therefore, materials get fulling mixing. Materials flow direction are determined by ribbon angle, direction, twining method. Material outlet are located in the middle of cylinder bottom. Outside ribbon driven by main shaft moves materials to discharging to ensure no discharging dead zone.
Technical Parameters:
| Type | PRM | ||||||||||
| Spec(m³) | 0.5 | 1 | 2 | 3 | 4 | 5 | 6 | 8 | 10 | 12 | 15 |
| Working capacity | 0.4-0.6 | ||||||||||
| Power | 5.5 | 11 | 15 | 18.5 | 22 | 30 | 37 | 45 | 55 | 55 | 75 |
| Speed(rpm) | 66 | 41 | 41 | 33 | 33 | 26 | 26 | 26 | 20 | 20 | 17 |
| Dimension L W H | 1672 | 1970 | 2480 | 2880 | 3026 | 3518 | 3905 | 4398 | 4500 | 4486 | 5363 |
| 1142 | 1437 | 1561 | 1895 | 1947 | 1945 | 1683 | 1960 | 2070 | 2250 | 2250 | |
| 1300 | 1500 | 1830 | 2083 | 2235 | 2233 | 2286 | 3150 | 2667 | 2737 | 3070 | |
| Weight(Kg) | 955 | 1400 | 2500 | 3300 | 3600 | 4620 | 5300 | 6800 | 8902 | 9520 | 9950 |
Our Advantages：
Product Details：
Application：
Company Advantages
· Polyc Machine vertical ribbon mixer is manufactured by our team of skilled experts as per the international quality standards.
· This product is strictly controlled by professional quality check team to avoid any flaws.
· With accumulated production experience for many years, Shanghai Polyc Technology Co.,Ltd becomes reliable for quality of vertical ribbon mixer.
Company Features
· Shanghai Polyc Technology Co.,Ltd is specialized in designing and manufacturing high-end vertical ribbon mixer.
· We have a team of dynamic individuals with a passion for change management and depth in their respective areas of expertise. Also, they can keep up with the latest market trends.
· Being a professional enterprise is the persisting goal for Polyc Machine. Inquire now!
Application of the Product
Polyc Machine's vertical ribbon mixer is available in a wide range of applications.
Our solutions are developed by understanding the customer's situation and combining the current market conditions. Therefore, they are all targeted and can effectively solve problems of customers.
