Polyc Machine Ribbon Powder Mixer Ribbon Powder Mixer Manufacturers
Product Features:
Ribbon Blenders consist of a U-shaped horizontal trough and a solid agitator shaft mounted with spokes that support outer and inner helical blades called ribbons. Powered by a gearmotor drive, the agitator rotates and produces a peripheral speed. The ribbons move material radially -- the outer ribbons move the ingredients in toward the blender’s center, and the inner ribbons move ingredients out toward the blender wall. The difference in the outer and inner ribbons’ speeds moves material laterally or axially (along the blender’s horizontal axis), in opposite directions. The radial and two-way axial mixing actions promote small-scale random motion (diffusion), large-scale random motion (convection), and shear resulting from particle-to-agitator, particle-to-wall, and particle-to-particle collisions.
Technical Parameters:
| Type | PRM | ||||||||||
| Spec(m³) | 0.5 | 1 | 2 | 3 | 4 | 5 | 6 | 8 | 10 | 12 | 15 |
| Working capacity | 0.4-0.6 | ||||||||||
| Power | 5.5 | 11 | 15 | 18.5 | 22 | 30 | 37 | 45 | 55 | 55 | 75 |
| Speed(rpm) | 66 | 41 | 41 | 33 | 33 | 26 | 26 | 26 | 20 | 20 | 17 |
| Dimension L W H | 1672 | 1970 | 2480 | 2880 | 3026 | 3518 | 3905 | 4398 | 4500 | 4486 | 5363 |
| 1142 | 1437 | 1561 | 1895 | 1947 | 1945 | 1683 | 1960 | 2070 | 2250 | 2250 | |
| 1300 | 1500 | 1830 | 2083 | 2235 | 2233 | 2286 | 3150 | 2667 | 2737 | 3070 | |
| Weight(Kg) | 955 | 1400 | 2500 | 3300 | 3600 | 4620 | 5300 | 6800 | 8902 | 9520 | 9950 |
Our Advantages：
Product Details：
Application：
Company Advantages
· The production process of Polyc Machine ribbon powder mixer follows an advanced technology.
· Our strict quality management system ensures that our products are always in the best quality.
· The product has been engaged in the industry for many years and is well-known with its outstanding features.
Company Features
· The business of Polyc Machine has been spreaded into oversea market.
· Our factory houses a series of advanced production facilities, including materials processing machines, testing machines, and assembly machines. This means that we can maintain our continuous and stable productivity.
· Shanghai Polyc Technology Co.,Ltd aims to become a top-notch ribbon powder mixer brand with international influence. Contact!
Application of the Product
The ribbon powder mixer produced by Polyc Machine is widely used in industry.
In addition to providing high-quality products, we also provide effective solutions based on the actual conditions and the needs of different customers.
